Sanyo SC-X1000P - Manual (Page 7)

NOTE : The parts marked with have special characteristics of safety,
if replace the mark parts,use only SANYO specified parts.
- 7 -
SC-X1000P (U.S.A.)
Parts List
(Power brush)
Key
No.
Key
No.
Parts No. Description Q'ty Parts No. Description Q'ty
COLOR CODE:N3-99T(SILVER),B-552(BLUE),N1-233/N3-78/N5-23(GRAY),NN-B(BLACK)
1 663 007 0086 POWER BRUSH COMP. KEYNO,2-60 1 51 663 000 9000 SCREW 3
2 663 000 8621 CASE CUSHION 1 52 663 007 0185 AC MOTOR (AC 120 V) 1
3 663 007 0093 SWITCH ORNAMENT (NN-B) 1 53 663 000 9024 CASE LOWER (NN-B) 1
4 663 007 0109 CASE UPPER (N3-99T) 1 54 663 000 9062 CAUTION LABEL A 1
5 663 007 0116 BUMPER (NN-B) 1 55 663 000 9079 SCREW 2
6 663 000 8669 LENS (N3-78) 1 56 663 007 0192 CORD ASSEMBLY 1
7 663 000 8676 CAUTION LABEL C 1 57 663 007 0208 PIN SLEEVE (N1-233) 1
8 663 000 8683 POLYURETHANE FORM 1 58 663 000 9093 CORD BUSHING (NN-B) 1
9 663 000 8690 SCREW 2 59 663 000 9109 CAUTION LABEL 1
10 663 000 8706 TORSION SPRING 1 60 663 007 0215 CAUTION LABEL(E) 1
11 663 000 8713 SWITCH BUTTON (NN-B) 1
12 663 000 8720 SWITCH SPRING 1
13 663 000 8737 MOVABLE REED (NN-B) 1
14 663 000 8744 MOVABLE REED BASE (NN-B) 1
15 663 000 8751 SCREW 2
16 663 000 3398 LAMP (15W 120V) 1
17 663 000 8768 LAMP HOLDER ASSEMBLY 1
18 663 000 8775 SCREW 7
19 663 000 8782 ROTARY PIPE COVER (N5-23) 1
20 663 000 8799 SHIELD SHEET 1
21 663 007 0123 CAUTION LABEL(E) 1
22 663 006 8670 ROTARY BRUSH COMP. 1
23 663 000 8829 BELT 1
24 663 000 8836 ROTARY SEAL C 2
25 663 000 8843 ROTARY SEAL B 2
26 663 007 0130 ROTARY PIPE (N1-233) 1
27 663 007 0147 BEND SET PIECE (N1-233) 2
28 663 007 0154 BEND COVER 1
29 663 007 0161 CRAMP HOOK (NN-B) 1
30 663 000 8294 CRAMP SPRING 1
31 663 007 0178 BEND 1
32 663 000 8973 ARM HOLDER 2
33 663 000 8850 CASE COVER (NN-B) 1
34 663 000 0700 WIRE CONNECTOR (CE-230) 3
35 663 000 8867 CORD ASSEMBLY (WHITE) L=115 1
36 663 000 8874 LEAD WIRE (BLACK) L=130 1
37 663 000 8881 MICRO SWITCH 1
38 663 000 8898 SWITCH HOLDER (NN-B) 1
39 663 000 8904 STEEL BALL 1
40 663 000 8911 HELICAL SPRING 1
41 663 000 8928 SWITCH LEVER ASSEMBLY 1
42 663 000 8263 SCREW (3X12) 2
43 663 000 8935 SWITCH ASSEMBLY A 1
44 663 000 8942 SWITCH BRACKET (NN-B) 1
45 663 000 9031 WHEEL REAR (NN-B) 2
46 663 000 9048 WHEEL FRONT (NN-B) 2
47 663 000 9055 SHAFT 2
48 663 000 8959 ROTARY SEAL A 2
49 663 000 8966 CORD ASSEMBLY (BLACK) L=75 1
50 663 000 8997 CORD INLET COVER (NN-B) 1
