- 5 -
SC-X1000P (U.S.A.)
Parts List
(Dust box)
Key
No.
Key
No.
Parts No. Description Q'ty Parts No. Description Q'ty
COLOR CODE:N3-99T(SILVER),B-552(BLUE),N1-233(GRAY),NN-B(BLACK)
1 663 006 9882 DUST BOX (B-552) 1 51 663 005 4772 DUST FILTER ASSEMBLY (N1-233) 1
2 663 006 9899 ORNAMENT PLATE (NN-B) 1 52 663 006 7178 DUST FILTER PACKING (N1-233) 1
3 663 006 9905 GEAR C (NN-B) 1 53 663 006 7185 DUST FILTER COVER (N1-233) 1
4 663 006 9912 SHIELD PLATE 1 54 663 000 3640 PACKING (DUST FILTER COVER) 1
5 663 006 9929 COLLECTING SHOE LEFT 1
6 663 006 9936 COLLECTING SHOE RIGHT 1
7 663 000 0847 SCREW (4X16) 18
8 663 006 6980 COLLECTING SHOE HOLDER 1
9 663 000 9239 SCREW (4X10) 1
10 663 006 9943 GEAR A (NN-B) 1
11 663 006 6997 CRAMP HOOK COVER (B-552) 1
12 663 006 9950 CRAMP BUTTON (NN-B) 1
13 663 006 7017 CRAMP SPRING (DUST) 1
14 663 006 7024 CRAMP SPRING 2
15 663 006 9967 CRAMP HOOK STOPPER (NN-B) 2
16 663 006 9974 LEAD WIRE (WHITE) L=250 1
17 663 006 9981 LEAD WIRE (BLACK) L=250 1
18 663 000 7709 COLLECTING SHOE 2
19 663 000 2872 SCREW (3X10) 2
20 663 000 7716 SLIP RING CLEANER 2
21 663 000 5880 SCREW 1
22 663 006 9998 AIR INLET (N3-99T) 1
23 663 007 0000 BASE HOLDER (N1-233) 1
24 663 000 9796 SLIP RING BASE UPPER 1
25 663 000 7655 JOINT SPRING C 2
26 663 000 9819 SLIP RING BASE LOWER 1
27 663 000 7679 SLIP RING 2
28 663 000 7686 AIR INLET PACKING 1
29 663 000 0243 SCREW (4X20) 3
30 663 007 0017 FRONT COVER (N3-99T) 1
31 663 006 7079 DUST BOX HANDLE LOWER 1
32 663 007 0024 BYPASS PACKING (N1-233) 1
33 663 006 7093 BYPASS COVER (N1-233) 1
34 663 006 7109 AIR INLET PACKING (N1-233) 1
35 663 000 3046 HELICAL SPRING (CRAMP) 1
36 663 007 0031 CRAMP LEVER (DUST) 1
37 663 007 0048 CRAMP HOOK (DUST)(NN-B) 1
38 663 000 2957 CRAMP SPRING A 1
39 663 006 7116 CAUTION LABEL 1
40 663 005 4703 CRAMP HOLDER (N1-233) 1
41 663 007 0055 GEAR B (NN-B) 1
42 663 000 2759 SCREW (4X14) 1
43 663 006 7130 PACKING A (N1-233) 1
44 663 007 0062 PRE FILTER ASSEMBLY (NN-B) 1
45 663 000 3688 PACKING (PRE FILTER ASSEMBLY LOWER) 1
46 663 006 7154 DUSTER ARM 4
47 663 007 0079 DUSTER HOLDER (NN-B) 1
48 663 005 4758 PACKING (DUST FILTER ASSEMBLY) UPPER 1
49 663 000 3503 PACKING (DUSTER FRAME) 1
50 663 006 7161 DUSTER FRAME (N1-233) 1
