- 1 -
FILE No.
PARTS LIST
Specifications
Wiring Diagram
Vacuum Cleaner
SC-180
(U.S.A.)
PRODUCT CODE NO.
1 - 326 733 51 ( S )
REFERENCE NO.
PL6510308-00
Power source : AC 120 V 60 Hz
Power consumption : 7 A
Motor revolution : 38,000 r.p.m.
Vacuum : 19,000 Pa
Dimensions : (Handy) (Upright)
L X W X H
13 - 19/32” X 7 - 3/32” X 8 - 27/32” 14 - 3/16” X 11 - 13/16” X 43 - 5/16”
(354 X 180 X 225 mm) (360 X 300 X 1,100 mm)
Net weight : 8 lbs. 6 ozs. ( 3.8 Kg )
Attachment : Hose, Turbine brush, Extension pipe,
Crevice tool, Upholstery tool & Dusting brush
Carbon brush
Black
Switch
Fuse
Red
A C
Stator
Stator
Rotor
Motor
