Parts List
(Main unit)
NOTE
: The parts marked with have special characteristics of safety,
if replace the mark parts,use only SANYO specified parts.
SC-X1000P
(U.S.A.)
Key
No.
Key
No.
Parts No.
Description
Q'ty
Parts No.
Description
Q'ty
COLOR CODE:N3-99T(SILVER),N1-233/N1-248(GRAY),NN-B(BLACK)
1 663 006 9714 HANDLE UPPER (N3-99T)
1
50 663 006 6751 MOTOR BASE PACKING (N1-233)
1
2 663 006 6492 HANDLE LOWER (N1-233)
1
51 663 006 6768 MOTOR CUSHION COVER (NATURAL)
1
3 663 000 0076 SCREW (4X16)
5
52 663 000 9567 MOTOR CUSHION OUTER
1
4 663 000 0847 SCREW (4X16)
44
53 663 006 6775 WHEEL CAP (N3-99T)
2
5 663 006 6508 HINGE PIN
1
54 663 006 6782 WHEEL REAR COMP. (N1-248)
2
6 663 006 6515 HINGE SPRING
1
55 663 005 7735 HOLDER PLATE (N1-233)
6
7 663 006 6522 HINGE
1
56 663 005 7728 WHEEL SMALL (N1-233)
6
8 663 006 9721 CRAMP LEVER (NN-B)
2
57 663 005 7711 SHAFT WHEEL
6
9 663 006 6546 CRAMP SPRING (HANDLE)
2
58 663 006 6799 CASE COVER (REEL SHAFT)(N1-233)
1
10 663 006 6553 CASE COVER (N3-99T)
1
59 663 006 6805 METAL COVER
2
11 663 006 6560 SUPPLEMENT COVER UPPER
1
60 663 006 6812 SCREW (4X17)
2
12 663 000 8263 SCREW (3X12)
5
61 663 000 5125 CAUTION LABEL
1
13 663 006 9738 JOINT SPRING RIGHT
1
62 663 006 9851 CASE LOWER (N1-248)
1
14 663 006 9745 JOINT SPRING LEFT
1
63 663 006 6836 CASE BUMPER (N1-248)
1
15 663 006 9752 CORD COVER (N1-233)
1
64 663 006 6843 CASTER (N1-248)
2
16 663 006 9769 OTHER STANDARD CORD
1
65 663 006 9868 AIR SPREADER
1
17 663 006 6577 CRAMP HOOK (N1-233)
2
66 663 000 8225 WHEEL SMALL (NN-B)
1
18 663 006 7284 AIR OUTLET OUTER (N3-99T)
1
67 663 000 8218 WHEEL SHAFT
1
19 663 006 7291 OUTLET FILTER ASSEMBLY
1
68 663 006 6850 CORD INLET COVER SMALL
1
20 663 006 6607 TOOL STORAGE (N3-99T)
1
69 663 006 6867 CORD INLET COVER (N1-248)
1
21 663 000 9499 BRAKE ARM BRACKET (N1-233)
1
70 663 006 6874 BOTTOM PACKING (N1-233)
1
22 663 006 6614 REEL KNOB (N1-233)
1
71 663 006 6881 CRAMP HOOK (N1-248)
3
23 663 006 9776 REEL BUTTON (NN-B)
1
72 663 000 3312 TRANSMISSON ASSEMBLY
1
24 663 006 9783 SWITCH BUTTON (NN-B)
1
73 663 006 6898 TRANSMISSION COVER (N1-248)
1
25 663 000 9451 FUSE ASSEMBLY (125V 15A)
1
74 663 006 6904 CASE LOWER BOTTOM LARGE
1
26 663 000 2896 SWITCH
1
75 663 006 6911 AIR INLET FILTER (GRAY)
1
27 663 006 9790 CORD ASSEMBLY (BLACK) L=300
1
76 663 006 9875 NAME PLATE
1
28 663 000 2193 WIRE CONNECTOR (CE-530)
2
77 663 006 6935 CASE LOWER BOTTOM SMALL
1
29 663 006 6645 HELICAL SPRING
4
30 663 006 6652 CASE UPPER (N3-99T)
1
31 663 000 9628 BRAKE ARM (N1-233)
1
32 663 000 9611 BRAKE SPRING
1
33 663 000 0236 BRAKE ROLLER ASSEMBLY B
1
34 663 006 9806 CORD REEL COMP. INCL/P.CORD
1
35 663 000 8034 POWER CORD (U2)
1
36 663 005 5557 REEL SUPPORTER ASSEMBLY
1
37 663 005 0378 SCREW (TORX SCREW)
1
38 663 006 9813 CORD ASSEMBLY (WHITE)
1
39 663 006 6683 POLYURETHANE FORM
2
40 663 006 6690 AIR OUTLET PACKING (N1-233)
1
41 663 006 6706 AIR OUTLET INNER (N1-233)
1
42 663 000 0243 SCREW (4X20)
4
43 663 006 6713 MOTOR BASE (NATURAL)
1
44 663 006 6720 SILENCER PIPE (NATURAL)
1
45 663 006 6737 MOTOR CUSHION REAR (NN-B)
1
46 663 006 9820 MOTOR COMP. (AC 120 V)
1
663 000 0298 CARBON BRUSH ASSEMBLY
2
47 663 006 9837 CORD ASSEMBLY (WHITE) L=400
1
48 663 006 9844 CORD ASSEMBLY (BLACK) L=450
1
49 663 005 6486 MOTOR CUSHION FRONT
1
