21
GC-STT BLOWER MOUNTING COMPONENTS
Ref. Part
No. Number Description
1 482406 Belt Cover, GC-STT - 52"
482378 Belt Cover, GC-STT - 61" & 72"
2 04029-04 Wingnut, Plastic 3/8 Small
3 482300 Cap, Square Vinyl
4 04021-08 Nut, Elastic Stop 1/4-20
5 461419 Adapter, Blower GC-STT
6 04040-14 Flatwasher, 1/4-.312 x .750 x .065
7 48137-04 Rubber Strap 7-3/4"
8 04001-59 Bolt, Hex Head 1/4-20 x 1-1/4"
9 481625-01 Knob W/Stud, 3/8-16 x 1-1/4"
10 04064-15 Clevis Pin, 5/16 x 1-1/2"
11 04069-03 Pin, Rue Cotter 5/16 Dia.
12 04067-07 Pin, Ring 1/2 x 2-1/4"
13 481547 Lanyard
14 482427 Pulley, 4-1/2" for 52" Deck
482377 Pulley, 5-1/2" for 61" Deck
482830 Pulley, 6-1/4" for 72" Deck
15 04012-04 Setscrew, 5/16-18 x 3/8"
16 04021-07 Nut, Elastic Stop 1/2-13
17 04030-06 Lockwasher, 1/2"
18 04040-07 Flatwasher, 1/2-.531 x 1.062 x .095
19 04001-71 Bolt, Hex Head 1/2-13 x 1-1/2" Grade 5
20 461418 Mounting Post Weldment, Blower - 52"
451413 Mounting Post Weldment, Blower - 61"
451657 Mounting Post Weldment, Blower - 72"
21 423427 Belt Cover, - 52"
423446 Belt Cover, - 61"
423940 Belt Cover, - 72"
22 04019-02 Nut, Serrated Flange 1/4-20
23 04017-05 Bolt, Hex Head 1/4-20 x 3/4"
24 04003-23 Bolt, Carriage 3/8-16 x 1"
25 04021-09 Nut, Elastic Stop 3/8-16
26 04041-07 Flatwasher, 3/8-.391 x .938 x .105
27 04001-09 Bolt, Hex Head 5/16-18 x 1"
28 04040-15 Flatwasher, 5/16-.375 x .875 x .083
29 04021-10 Nut, Elastic Stop 5/16-18
30 04001-12 Bolt, Hex Head 5/16-18 x 1-3/4"
31 423629 Baffle, 52"
423448 Baffle, 61"
423932 Baffle, 72"
32 423956 Baffle, 52" Deck
423957 Baffle, 61" Deck
423958 Baffle, 72" Deck
