- 10 -
2$ Button for radio station search downwards (DOWN)
2% Button for radio station search upwards (UP)
2^ Button for save position 1/6, set alarm time 1 (MEM. 1/6, AL.1 SET)
2& Button for save position 2/7, set alarm time 2 (MEM. 2/7, AL.2 SET)
2* Button for save position 3/8, adjust minutes (MEM. 3/8, MIN.+ SET)
2( Button for save position 4/9, adjust time (MEM. 4/9, TIME SET)
3) Button for save position 5/10, adjust hours
(MEM. 5/10, HOUR+ SET)
3! Loudspeakers
3@ Button for projection of the time On/Off (PROJECTION ON/OFF)
3# Rotatable projection lens
3$ Focusing slider (FOCUS)
3% Adjustment wheel to turn the time projection (ROTATE PROJECTION)
3^ Button to turn the time projection through 180°
(PROJECTION REVERSE)
3& Power adapter connection DC 7,5 V
3* Wire aerial
3( Battery compartment cover
4) Reset button
4! Power adapter with plug and cable
4@ Connector plug
