Command List
AF Active Time
1)
00
to
FF
AF Interval Time
1)
00
to
FF
Spot AE X position
00
to
0F
Spot AE Y position
00
to
0F
R Gain
00
to
FF
B Gain
00
to
FF
Aperture Level
00
to
0F
NR Level
00
to
05
V-Phase
00
to
020C (NTSC)
0270 (PAL)
AE Response
01
to
30
AutoICR ON
t
00
to
1C
OFF Threshold Level
MD Threshold Level
00
to
FF
MD Interval Time
1)
00
to
FF
MD Set Horizontal Position
00
to
0C
MD Set Vertical Position
00
to
08
Color Enhancement
00
to
7F
Threshold Level
Color Enhancement
00
to
7F
Hysteresis Width
Color Enhancement
00
to
7F
Fixed Color Y
Color Enhancement
00
to
7F
Fixed Color Cr
2)
Color Enhancement
00
to
7F
Fixed Color Cb
2)
Others
1)
Unit: One second
2)
40 center
Register Setting
Register No.
Value
VISCA
00
9600 bps
Baud Rate
1)
00
01
19200 bps
02
38400 bps
OSD
60
00
English
Language
03
Chinese
CCD Scanning
72
00
Interlaced
Mode
1)
01
Progressive
Digital Output
73
00
60p/50p
Mode
1)
(30p/25p
×
2)
* Enabled when
Clock rate:
the CCD
56 MHz
Scanning Mode
01
60p/50p
is Progressive.
Clock rate:
56 MHz
04
30p/25p
Clock rate:
28 MHz
(Stop analog
output)
Zoom Limit
1)
50
00-FF
Wide Limit
(0: Disabled)
51
00-FF
Tele Limit
(0: Disabled)
E-Zoom Max
1)
52
00-FF
Max. digital
zoom ratio =
256 ÷
(256-Value)
StableZoom
53
00
OFF
01
ON
FocusTrace
54
00
OFF
@ZoomDirect
1)
01
ON
FocusOffset
55
00-FF
00: None to
@DomeCover
FF: Max.
1)
The register settings are enabled when the power is turned off and then
back on again. After turning the power back on again, verify that the
mode settings have been changed.
