Sony FCB-EX1020 - Manual (Page 53)

53
Command List
Enlargement Function2 Query Command ............. Command Packet 8x 09 7E 7E 04 FF
Byte Bit Comments
7
6
Destination Address
5
0
4
3
2
Source Address
1
0
7 0 Completion Message (50h)
6 1
5 0
1
4 1
3 0
2 0
1 0
0 0
7 0
6 0
5 0
2 4 0
3 0
2 WideD mode (0: OFF, 1: ON,
1 2: Auto ON/OFF, 3: ON
0 (RatioFIx), 4: ON (Dver))
7 0
6 0
5 0
3 4 0
3 WideD screen display
2 0: Combined image
1: Long/short division
2: Long-time 3: Short-time
1 WideD detection sensitivity
0 0: L 1: M 2: H
7 0
6 0
5 0
4 4 0
3 WideD blocked-up shadow
2 correction level 0: L 1: M 2: H
3: S
1 WideD blown-out highlight
0 correction level 0: L 1: M 2: H
7 0
6 0
5 0
5 4 0
3
2 WideD short exposure
1 Exposure ratio (H)
0
Byte Bit Comments
7 0
6 0
5 0
6
4 0
3
2 WideD short exposure
1 Exposure ratio (L)
0
7 0
6 0
5 0
7
4 0
3 0
2 0
1 0
0 0
7 0
6 0
5 0
8
4 0
3 0
2 0
1 0
0 0
7 0
6 0
5 0
9
4 0
3 0
2 0
1 0
0 0
7 0
6 0
5 0
10
4 0
3 0
2 0
1 0
0 0
Byte Bit Comments
7 0
6 0
5 0
11
4 0
3 0
2 0
1 0
0 0
7 0
6 0
5 0
12
4 0
3 0
2 0
1 0
0 0
7 0
6 0
5 0
13
4 0
3 0
2 0
1 0
0 0
7 0
6 0
5 0
14
4 0
3 0
2 0
1 0
0 0
7 1 Terminator (FFh)
6 1
5 1
15
4 1
3 1
2 1
1 1
0 1
