91
Connections for an A/B Roll Editing System
Settings on an editing control unit
When connecting an editing control unit, make the settings
as follows, according to the model.
PVE-500
No settings are required.
BVE-600/900/910/2000 (NTSC model) or FXE-100/
120
Set the VCR constants as follows.
BVE-600/900/910/2000 (PAL model) or FXE-100P/
120P
Set the VCR constants as follows.
RM-450/RM-450CE
Set the DIP switches as follows.
• Left switches
• Right switches (RM-450)
)
• Right switches (RM-450CE)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
80 18 00 96 05 05 03 80 0A 08 FE 00 80 5A FF
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
81 17 00 7D 05 05 02 80 0A 07 FE 00 80 4C FF
7 6 5 4 3 2 1 0
OFF
− −
OFF
− − − −
7 6 5 4 3 2 1 0
OFF
−
OFF ON OFF OFF ON ON
7 6 5 4 3 2 1 0
ON
−
OFF ON OFF OFF ON ON
