85
Connections for an A/B Roll Editing System
Connections for an A/B Roll Editing System
The following is an example configuration of A/B roll
editing system using this unit.
In this configuration, a DSR-1500A/1500AP unit is used
as the recorder and this unit as player 1, and an analog
Betacam UVW-1600/1600P Videocassette Player unit is
used as player 2. To create a final tape (a tape that contains
a completely packaged program) in Betacam format, use a
DVCAM VCR such as the DSR-1500A/1500AP as the
recorder.
Notes
• This application requires the DSR-1500A/1500AP unit
used as the recorder to be fitted with the optional DSBK-
1504/1504P board.
• The DSR-1500A/1500AP units shown in the following
figure are fitted with the optional DSBK-1501 and
DSBK-1504/1504P boards.
The purpose of the following figure is to indicate the flow
of signals among the component devices in the system.
The specific connections and settings are described
beginning on page 87.
