7. 1.5 ft. guide line alignment

(flashing blue rectangle)

7-1. Each time the control switch is pressed, the

1.5 ft. guide line moves farther from the
vehicle. Continuously pressing the control
switch moves the line farther away until it
exceeds a certain range and the line
returns to the position closest to the vehicle.

Set the1.5 ft. guide line to match the 1.5 ft.
marker.

7-2. Press and hold the control switch for more

than two seconds.
The 1.5 ft. guide line alignment is now set and
also 6 ft. guide line alignment is now set
automatically and all the alignment settings
are now completed.
The screen will disappear after displaying
the

view-from-top

for three seconds.

After turning the ignition switch off and removing the auxiliary items used for alignment, move the

vehicle to a safe place.

• The 6 ft. guide line may not display as a

result of camera installation conditions.

Note
