No. of
config.
Denomination / description
Units Fact.
value
Mod.
value
1298 Increment step of the adaptive low voltage method
mV/cell
20
1300 Number of overloads permitted before definite stoppage
--
3
1303 Number of battery overvoltages accepted before definite stoppage --
3
1304 Number of battery undervoltages permitted before final stop
--
3
1307 Reset voltage for adaptive correction
V/cell
2.2
1309 Minimum ACin voltage to authorise charging
Vac
185
1403 Period for counting battery overvoltages
sec.
60
1404 Period for counting battery undervoltages
sec.
0
1432 Maximum ACin voltage to switch to inverter mode
Vac
270
1433 Adaptation range of the charge current according to the input
voltage
V
20
1436 Allow to exceed AC input current without opening the transfer relay y/n
yes
1470 ACin voltage hysteresis for closing the transfer relay
Vac
10
1485 Automatic earth-neutral connection in inverter mode
y/n
no
1488 Critical under voltage of the battery
V/cell
1.5
1505 Delta of higher frequency accepted
Hz
15
1506 Delta of lower frequency accepted
Hz
5
1516 Auxiliary contact 1 deactivated by floating mode
y/n
yes
1517 Auxiliary contact 2 deactivated by floating mode
y/n
no
1527 Decrease max input limit current with AC-In voltage
o/n
n
1528 Delay before closing transfer relay
Min.
0
1532 Kind of dynamic compensation
Auto/Man Auto
To modify the configurations, please refer to the operating instructions for the RCC-02/03
remote control
