Installing the BM85
890 USE 103 00
81
5.5.2
Serial Port Parameters Label
On this label enter the parameters you are using at each of the serial
ports. Place the label on the BM85 so that it can readily identify the
parameters in your application.
Figure 24 shows the layout of the label.
MODBUS
PORT 1
PORT 2
PORT 3
PORT 4
MASTER / NTWK /
SLAVE (ADDRESS)
ASCII / RTU
BAUD RATE
STOP BITS / PARITY
TIMEOUT (100’S ms)
MODEM BOOSTER
Figure 24
Serial Port Parameters Label
