Page 60
Configuring the Modbus Models
890 USE 103 00
50
3.10 Your V4 Screen
3.10.1
Your V4 Screen Layout
Figure 13 shows a typical V4 screen. Valid commands are listed on the
screen.
SAVE AND DEFAULT CONFIGURATION [V4]
>>Valid Commands:[V1 V2 V3 V4 W D] Keys:[Enter Esc ?–help]
Active Port 1>> __
STATUS: Configuration parameters –– CHANGED –– since last save
Figure 13
Typical V4 Screen: Save or Initialize the Configuration
