Configuring the Programmable Models
890 USE 103 00
63
4. Start your Borland compiler development environment as described
in your compiler documentation.
5. Update the BM85 Project file BM85.PRJ to set the correct directory
paths for your Borland environment. For example, in the Borland
3.1 environment, you can use the following key sequence:
Key Sequence
Purpose
Alt–P
Project open
BM85.PRJ
Project name
Alt–O D
Option directories
(paths)
Update the paths for your INCLUDE and LIBRARY directories
6. If either of these parameters is true, continue with Step 7. If
neither is true, skip Step 7 and go to Step 8.
h Your SA85/SM85 interrupt is set to a vector other than 5C
h Your BM85 Modbus Plus node address is other than 4.
7. Update the BM85LOAD and MBPSTIM command lines in the BM85
project's TRANSFER menu to use the new parameters. In the
Borland 3.1 environment, you can use the following key sequence:
Key Sequence
Purpose
Alt–T
Transfer menu
Select command line
Select the BM85 DOWNLOAD or MBPLUS STIMULATE line
Alt–E
Edit
Alt–C
Command line
Enter parameters
Set the parameters as they are used in your application
Alt–M
Modify
Alt–K
OK
8. When you have updated your project file, close the project. In the
Borland 3.1 environment, you can use the following key sequence:
Key Sequence
Purpose
Alt–C
Project close
