In the video input/output conversion table classified by the menu
settings
For details on “Resolution” menu setting, see “Settings for the video (Video settings menu)”
(page 56) and on operating, see “Converting analog video input signals” (page 87).
a : Video signals are converted and output through the video converter.
f : The same type of signal as that of the input signal is output. Video signals are not converted.
X : Video signals are not output.
a)This resolution is set automatically, depending on the connected monitor.
b)When the TV is connected to jacks other than the HDMI jacks, 480i/576i signals are output when
“Resolution” is set to “AUTO.”
c)480p/576p signals are output even if 480i/576i is set.
d)Video signals without copyright protection are output based on the settings menu. Video signals with
copyright protection are output as 480p.
Notes
• Video signals are not output from the COMPONENT VIDEO MONITOR OUT or MONITOR VIDEO OUT
jack when the monitor, etc., is connected to the HDMI OUT jack.
• If you select a resolution that the connected TV does not support in the “Resolution” menu, the images from
the TV cannot be output correctly.
• Converted HDMI image output signals do not support “x.v.Color.”
“Resolution”
menu setting
HDMI OUT jack
COMPONENT
VIDEO MONITOR
OUT jacks
MONITOR VIDEO
OUT jack
DIRECT
Component video
X
f
X
Video
X
X
f
AUTO (initial
setting)
Component video
a
a)
a
b)
a
b)
Video
a
a)
a
b)
a
b)
480i/576i
Component video
a
c)
a
a
Video
a
c)
a
a
480p/576p
Component video
a
a
X
Video
a
a
f
720p, 1080i
Component video
a
a
d)
X
Video
a
a
d)
f
1080p
Component video
a
f
X
Video
a
X
f
