General guide
3
General guide
The following illustrations show the major component parts of the your printer.
For a description of what each part does, see the Glossary on page 72 of this
manual.
Control panel
Front cover
Automatic sheet feeder
Paper support
Interface connector
Paper button
Power button
Paper tray cover
Platen
Cartridge
Print head
