LENS REPLACEMENT AND INSTALLATION PROCEDURE
-2-
2
Pulling up Light Block Sheet Holder and Cover Plate,
remove them. (See Fig-2)
Fig-1
Front Cover
A
Fig-2
Fig-3
1
Disconnect the power cord from AC outlet.
Remove 5 screws (A) from the front cabinet.
Pulling up the front cover and remove it. (See Fig-1.)
3
Remove the cover plate from the light block sheet
holder . (See Fig-3)
A
A
Cover Plate
Light Block Sheet Holder
Cover Plate
