Instructions for the User
4. GETTING TO KNOW YOUR APPLIANCE
The drawings which follow illustrate all the zones which may be included in the
product you purchase, one by one.
In hobs ordered "to the centimetre" the controls may be located on the front
(as shown here) or vertically.
Auxiliary Burner
(AUX)
Small cooking zone
Residual heat
warning lights
Semi-rapid (SR)
burner
Large cooking zone
Barbeque heating
element thermostat
light
Rapid Burner (R)
Barbeque heating
element
Green power on
light
Ultrarapid Burner
(UR3)
Heating element
safety device
Frier red thermostat
light
Ultrarapid
Burner (UR3)
Raised spoke pan
stand
Heating element
