DISPLAY PANEL
R E C
TIMER
PLAY NTSC
M
SP LP
ST BIL
+8
4
0
6
10
–20dB
NORM L R
! @ 9 8
3 4 6 7 5 2 1
0
INDEX (cont.)
1 B.E.S.T. Picture System Display (
੬
pg. 18)
Audio Level Indicator
2 PLAY Indicator (
੬
pg. 10)
3 REC[ORD] Indicator (
੬
pg. 15)
4 NTSC Indicator (
੬
pg. 32)
5 Tape Speed Indicators (
੬
pg. 15)
6 ST[EREO] Indicator (
੬
pg. 17)
7 BIL[INGUAL] Indicator (
੬
pg. 17)
8 Audio Mode Indicator (
੬
pg. 14)
9 "Cassette Loaded" Mark
0 Counter Memory Indicator (
੬
pg. 12)
! "TIMER" Indicator (
੬
pg. 22)
@ Clock/Counter/Channel Display (
੬
pg. 6)
