JVC Everio GZ-MG37E User Manual
Gz-mg37e/ek gz-mg27e/ek, Instructions

MasterPage: Cover
GZ-MG37E/EK
GZ-MG27E/EK
LYT1537-016A
EN
ENGLISH
HARD DISK CAMCORDER
GETTING STARTED
RECORDING
DUBBING
To deactivate the demonstration mode, set “DEMO
MODE” to “OFF”. (
FURTHER
INFORMATION
INSTRUCTIONS
PLAYBACK
EDITING/PRINTING
MENU SETTINGS
Dear Customer,
Thank you for purchasing this hard
disk camera. Before use, please read
the safety information and
precautions contained in pages 4 and
5 to ensure safe use of this product.
