INITIAL SETTING (cont.)
Analog Tuner
Setting Setting channels automatically
— Auto Channel Set (Analog)
Use Auto Channel Set only if channels have not been set
correctly by the Plug & Play setting. If you want to add or
delete channels, use Manual Channel Set (Analog) (A
page 19).
A
Access Main Menu screen
Press [MENU].
B
Access Tuner Set Up screen
C
Perform Auto Channel Set
D
Return to normal screen
Press [MENU].
• Turn on the VCR and the TV, and select the AV
mode on the TV.
• Set the [VCR/TV/CABLE/DBS] selector on the
Remote to [VCR].
B - C
D
A
VCR
TV
CABLE
/DBS
A Press [D E] to
move the arrow to
“TUNER SET UP”,
then press [G] or
[OK].
B Press [D E] to
move the arrow to
“TUNER SET”,
then press [G] or
[OK].
You can
automatically set the
receivable channels
in your area in the
order of their
frequencies.
Press [FG] to move
the arrow to “AUTO
CH SET”, then press
[OK].
NOTES:
• When Auto Channel
Set is complete,
“SCAN COMPLETED”
appears on screen.
• If the scan was
unsuccessful, “SCAN
COMPLETED – NO
SIGNAL FOUND –”
appears on screen.
Check the
connections, then
select “RETRY” to start
again, or select
“EXIT”.
INFORMATION
The VCR selects the correct band (TV or CATV)
automatically during Auto Channel Set.
The selected band will be displayed on the right side
of “BAND” on the Tuner Set Up screen.
THEN PRESS [OK]
TUNER SET
BAND
AUTO CH SET
MANUAL CH SET
TV
CABLE SET UP DBS SET UP
SELECT WITH ARROW KEYS
SELECT
OK
EXIT
MENU
FUNCTION SET UP INITIAL SET UP TUNER SET UP
THEN PRESS [OK]
BAND
AUTO CH SET
MANUAL CH SET
TV
DBS SET UP
SELECT WITH ARROW KEYS
SELECT
OK
EXIT
MENU
TUNER SET CABLE SET UP
FUNCTION SET UP INITIAL SET UP TUNER SET UP
THEN PRESS [OK]
AUTO CHANNEL SET
SCANNING...
PRESS [MENU] TO END
DBS SET UP
SELECT WITH ARROW KEYS
SELECT
OK
EXIT
MENU
TUNER SET CABLE SET UP
FUNCTION SET UP INITIAL SET UP TUNER SET UP
