M-series Routing Platforms

Rich Packet Processing

A broad portfolio of services can be layered on top of VPNs for additional
revenue generation. A comprehensive suite of multicast capabilities, including
multicast over MPLS VPNs, enables efficient distribution of premium content.
Hardware-based IPv6 and a number of IPv6 migration tools such as IPv6 over
MPLS ease access to the benefits of this next-generation IP protocol without
performance compromise. NAT and stateful firewall can be configured per VRF
to enable network-based security for additional revenues and IPSec can be
used to support a premium security service for end users with high security
requirements. The M-series Service-Built Edge is continuously enhanced with
new packet processing capabilities to ensure maximum revenue generation
opportunities.

Highly Reliable

The M-series service-built architecture has been fundamentally constructed with
scale and stability in mind, including the modular and fault-protected design of
JUNOS software along with a rigorous system testing process. Furthermore, all
M-series routers offer redundant power and cooling and the M10i, M20, M40e,
M160, and M320 offer fully redundant hardware including redundant Routing

Engines and Switching/Forwarding Engine Boards. JUNOS software features
enhance this redundant architecture by enabling non-stop forwarding in the
event of a routing engine failure via a Hitless Switchover and when a minor
software upgrade is required by supporting In-service Software Upgrades. This
functionality augments other high availability capabilities that include graceful
protocol routing restart, MPLS fast reroute, VRRP, SONET APS, SDH MSP, BFD,
and LACP.

Robust Security

All M-series platforms support highly scalable J-Protect filtering capabilities,
unicast reverse path forwarding and high performance rate limiting for
industry-leading DOS attack protection. The J-Protect security capabilities of the
M-series platforms can be further enhanced with the Adaptive Services PIC that
accelerates, in hardware, additional network-based security services such as
high-speed NAT, stateful firewall with attack detection, and J-Flow accounting.
With the rich feature set of JUNOS software combined with industry-leading
ASIC technology, the M-series Service-built Edge provides a new level of reliable
and secure service delivery at the edge of service provider networks.

Advantage

Features

Benefits

Features

Benefits

New Service
Models

• Industry's most comprehensive VPN portfolio meets the largest

number of customer needs and maximizes provider revenues

• Run Layer 2 Virtual Circuit, Layer 2 VPN, Layer 2.5

Interworking VPNs, Layer 3 2547 VPN, VPLS, IPSec, IP over
IP, GRE simultaneously

• Highly scalable, supporting thousands of VPNs

• Granular QoS with low latency and jitter performance to support

voice, video, and other real time applications

• Per DLCI, per VP, per VC, per VLAN, per channel (DS0),

and per port QoS

• Classification, rate limiting, shaping, weighted round robin

scheduling, strict priority scheduling, weighted random
early detection, random early detection, and packet
marking

• Mapping Layer 2 (802.1p, CLP, DE) to Layer 3 QoS (IP

DSCP, MPLS EXP)

• Hardware-based IPv6 performance, IPv6 over MPLS, IPv6 over

IPv4 GRE tunnels, and IPv6/IPv4 dual stack functionality

• Robust multicast support including IGMP v1/v2/v3, PIM-SM, PIM-

DM, MLD, SSM, RP, MSDP, BSR, multicast in MPLS/BGP VPNs to
support resource-efficient delivery of high-value content

• Network-based security services including NAT and stateful

firewall, and NAT and stateful firewall per VRF

• MLPPP, MLFR .15 and MLFR .16, 802.3ad (including LACP) for

aggregated links

• J-Flow accounting, source class usage, and destination class

usage for flexible billing on a per application or per CoS resource
usage basis and for distance-based billing.

• Multivendor network management solution through partnerships

• Industry-leading, XML-based JUNOScript API facilitates

third-party and in-house OSS development

Services
Everywhere

• One feature-rich JUNOS image runs across all M-series

platforms, ensuring consistent services and enabling
providers to market all services to all users regardless of
connection or serving area density

• From the smallest PoPs to the largest PoPs

• Over virtually any access technology including ATM,

FR, Ethernet, and TDM connections

• At any speed from DS0 to OC-192/STM-64

• Lowers operational costs

• Seamless migration to larger platforms to meet network

growth
