Ⅵ Compliant Signal Formats of Each Input Card
Input Signals IF-C01PNG IF-C01COMG IF-C01SDG IF-C01HSDG
NTSC (3.58 MHz) R — — —
PAL (4.43 MHz) R — — —
Black-and-White (50 Hz/60 Hz) R — — —
480/60i (525i) — R R —
480/60p (525p) — R — —
576/50i — R R —
576/50p ( * 1) —
⅜
— —
720/60p (720p) — R — R
1080/50i ( * 1) —
⅜
—
⅜
1080/60i (1125i) — R — R
1035/60i (1125i) ( * 1) —
⅜
—
⅜
1080/24pSF — R — R
R : Input possible. Pre-set.
⅜
: Input possible. Not pre-set. Any adjustments required in some cases.
– : Input impossible
* 1 : 1080/50i, 1035/60i and 576/50p are not pre-set. When these signals are input, some adjustments are required.
Usage Precautions
● The selected signal is output from the SWITCHED OUT terminal only when the monitor’s power is turned on.
● The output signal from the SWITCHED OUT terminal is the one that is selected from the signals input to SDI 1 / HD SDI 1 or
SDI 2 / HD SDI 2.
The table below shows the connection between the INPUT SELECT buttons (input signal selection) and the input/output of
the SDI / HD SDI input card.
Selected INPUT SELECT Buttons Signal Output from the SWITCHED OUT Terminal
A, C, E Signal from SDI 1 / HD SDI 1
B, D, F Signal from SDI 2 / HD SDI 2
This section explains the usage precautions and connection examples when using the SWITCHED OUT terminal of the SDI / HD
SDI input card.
APPENDIX: CONNECTION EXAMPLES FOR THE
SDI / HD SDI INPUT CARD
