8
Parts Identifi cation
(cont.)
Remote control
POWER OFF button
Turns off the monitor (see page 14).
SET-UP button
Displays the set-up menu (see page
17).
MENU/EXIT button
Displays the main menu (see page
17).
PICTURE MODE buttons
Changes the picture mode (see
page 16).
DUAL DISPLAY buttons
Activates/deactivates the dual
display mode (see page 16).
AUDIO MODE buttons
VOLUME +/– buttons
Adjusts the volume level (see page
14).
STEREO, MONO buttons
Changes the audio mode (see page
16).
MUTING button
Turns off the volume immediately
(see page 14).
POWER ON button
Turns on the monitor (see page 14).
ASPECT button
Changes the aspect ratio (see page
15).
DISPLAY button
Displays the information of the
current input (see page 15).
5∞ 2 3 buttons
Operates the menu (see page 17).
OK button
Enters the password for the Power-
on Lock (see page 30).
INPUT SELECT buttons
Selects the input (see page 14).
A (VIDEO) button
Selects the input to the VIDEO IN
A terminal (Input A).
B (RGB/COMPO./DVI) button
Selects the input to the VIDEO IN
B terminal (Input B).
C, D (SLOT-1) buttons
Selects the input to the optional
input card inserted in the slot 1
(Input C/D).
E, F (SLOT-2) buttons
Selects the input to the optional
input card inserted in the slot 2
(Input E/F).
Inserting the batteries
Use two AA/R6 dry cell batteries.
Insert the batteries from the
· end, making sure the ª and · polarities are correct.
• Follow the warnings printed on the batteries.
• Battery life is about six months to one year, depending on how much you use
the remote control.
• The batteries we supply are only for setting up and testing your monitor,
please replace them as soon as you need to.
• If the remote control does not work properly, replace the batteries.
