TM-6710/6710CL High-Speed Progressive Scanning CCD Camera
3.2.1 Mode Control Switches (TM-6710)
3.3 Modes of Operation
3.3.1 Shutter Operation
The TM-6710 has a substrate drain electronic shutter mechanism which provides a superb picture at
various speeds without smearing. Manual shutter speed control can be selected at 1/250, 1/500, 1/1,000,
1/2,000, 1/4,000, 1/8,000, 1/16,000 or 1/32,000 sec. rate.
Note: Some slow speed shutter rates will not apply to partial scanning.
Mode Control Switch Up/Down Switch
0 Normal mode
1 Gain control (A/B) up - increase gain of Ch. A
down - decrease gain of Ch. A
2 Gain (A/B) fine tune up - increase gain of Ch. A
down - decrease gain of Ch. A, while decrease/increase gain of Ch. B,
at 5:1 ration
3 Main Vref control up - increase gain of Ch. A
down -decrease A/D voltage reference of Ch. A & Ch. B
4 Vref balance control up - increase gain of Ch. A
down - increase/decrease A/D voltage reference of Ch. A, while
decrease/increase gain of Ch. B
5 Gain selection up: 9dB down: 12dB
6 Gain selection up: 18dB down: 22dB
7 Clock selection up: 120Hz down: 60Hz
8 Async/Manual shutter up: Manual down: Async
9 Factory set recall up/down - recall only
A Power up (recall or save) up: recall down: save
B-C User page storage (store
user settings) up: recall down: save
D Direct shutter up - increase manual shutter speed
down - decrease manual shutter speed
E Partial scan up: 100 lines down:
F Partial scan up: normal scan down: 200 lines
