Installation
TM-6710/6710CL High-Speed Progressive Scanning CCD Camera
2.2.1 (c) 51-Pin Connector
The TM-6710 has a 51-pin connector for RS-644 digital output (using B channel digital output to
configure single channel).
FIGURE 3.
51-Pin Connector
2.2.1 (d) Camera Link Connector
The TM-6710CL has a 26-pin connector on the rear panel to output Camera Link data. The connector
pinout is shown in Figure 4 below.
FIGURE 4.
Camera Link Connector
Pin#
Description
Pin#
Description
Pin#
Description
1
A0+
18
CLK+
35
CLK-
2
B0+
19
A0-
36
GND
3
A1+
20
B0-
37
VCC (jumper)
4
B1+
21
A1-
38
VCC (jumper)
5
A2+
22
B1-
39
EXT. HD
6
B2+
23
A2-
40
TXD
7
A3+
24
B2-
41
LPULSE
8
B3+
25
A3-
42
RXD
9
A4+
26
B3-
43
VINIT
10
B4+
27
A4-
44
INTEG
11
A5+
28
B4-
45
EXP-
12
B5+
29
A5-
46
EXP+
13
A6+
30
B5-
47
LDV-
14
B6+
31
A6-
48
LDV+
15
A7+
32
B6-
49
FDV-
16
B7+
33
A7-
50
FDV+
17
GND
34
B7-
51
GND
1
18
36
51
19
35
13 12 11 10 9 8 7 6 5 4 3 2 1
26 25 24 23 22 21 20 19 18 17 16 15 14
13
1
26
14
