Basic Installation Steps
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
: Remove existing speaker.
: Position new speaker and align with existing mounting
holes, when possible.
: Attach the positive (+) and negative (-) speaker terminals
to both the woofer and tweeter (see FIGURE 2). Be sure
to observe proper polarity when connecting the wires.
: If not using factory grilles, attach grille.
: Mount speaker (using factory hardware when possible).
: Reconnect negative battery terminal.
INSTALLATION
FIGURE 2 - CONNECTING SPEAKER WIRES
FIGURE 3 - REAR DECK INSTALLATION FIGURE 1 - DOOR PANEL INSTALLATION
Speaker Door Panel
3
Grille
Copper Wire = Positive
Silver Wire = Negative
