Page 54: On the front panel, Select and play any source, Press surround
50
On the front panel:
Before you start, remember...
There is a time limit in doing the following steps. If the setting is
canceled before you finish, start from step
2 again.
1
Select and play any source.
• Surround/DSP modes are not available when selecting “A
MULTI” in the audio input setting (see page 20) or when
multi channel PCM (see page 47) signals recorded in DVD-
Audio are coming in.
• Make sure you have selected the input mode (analogue or
digital) correctly.
2
Press SURROUND.
MULTI JOG now works for selecting Surround/DSP modes.
3
Turn MULTI JOG to select the Surround/DSP
mode you want.
Ex.: When “DOLBY DIGITAL” is selected for Dolby Digital
multi-channel software:
*
1
“AUTO SURROUND” is the initial setting.
*
2
Available Surround modes vary depending on the speaker
settings and the incoming signals. For details, see page 49.
*
3
If an incoming signal is a multi-channel (more than 2
channel) digital signal, “MONO FILM” is not available.
*
4
If “SURROUND SPK” is set to “NO,” “ALL CH STEREO” is
not available.
To cancel Surround/DSP modes
Turn MULTI JOG so that “SURROUND OFF” appears on the
display.
When you select “AUTO SURROUND”
You can enjoy the Surround mode easily.
• For details about the Surround modes, see page 49.
• When “AUTO SURROUND” is activated, the AUTO SURR indicator
lights up on the display.
How does “AUTO SURROUND” work?
• If a multi-channel signal comes in, an appropriate Surround
mode will be selected automatically.
• If a Dolby Digital 2-channel signal with surround signal comes
in, “PLIIx MOVIE” or “PLII MOVIE” will be selected.
• If a Dolby Digital 2-channel signal without surround signal
comes in, “SURROUND OFF (stereo)” will be selected.
• If a Linear PCM signal comes in, “SURROUND OFF (stereo)”
will be selected.
NOTE
“AUTO SURROUND” does not take effect in the following cases:
– While playing an analogue source,
– While selecting one of the fixed digital decode mode—“DOLBY
DIGITAL” or “DTS” (see page 21).
Activating the Surround/DSP modes
Available Surround/DSP modes vary depending on the speaker
settings and the incoming signals. For details, see page 49.
Activating one of the Surround/DSP modes automatically
recalls the memorized settings and adjustments.
• To adjust the speaker output level, see page 37.
• When activating one of the Surround/DSP modes, you
can adjust CENTER TONE. (See page 39.)
• When activating one of the Surround/DSP modes
(except PLIIx MUSIC, PLII MUSIC, NEO:6 MUSIC, and
ALL CH STEREO), you can adjust CNTR ALIGNMENT.
(See page 39.)
• When activating “NEO:6 MUSIC,” you can adjust CENTER
GAIN. (See page 39.)
• When activating the DSP mode (except ALL CH
STEREO), you can adjust the following settings:
EFFECT (see page 38)
LIVENESS (see page 39)
ROOM SIZE (see page 38)
• When activating “PLIIx MUSIC” and “PLII MUSIC”, you
can adjust the following settings:
CENTER WIDTH (see page 39)
DIMENSION (see page 39)
PANORAMA (see page 39)
Selecting the Surround/DSP modes
From the remote control:
1
Select and play any source.
• Surround/DSP modes are not available when selecting “A
MULTI” in the audio input setting (see page 20) or when
multi channel PCM (see page 47) signals recorded in DVD-
Audio are coming in.
• Make sure you have selected the input mode (analogue or
digital) correctly.
2
Press SURROUND repeatedly to select the
Surround/DSP mode you want.
Ex.: When “DOLBY DIGITAL” is selected for Dolby Digital
multi-channel software:
*
1
“AUTO SURROUND” is the initial setting.
*
2
Available Surround modes vary depending on the speaker
settings and the incoming signals. For details, see page 49.
*
3
If an incoming signal is a multi-channel (more than 2
channel) digital signal, “MONO FILM” is not available.
*
4
If “SURROUND SPK” is set to “NO,” “ALL CH STEREO” is
not available.
To cancel Surround/DSP modes
Press SURROUND repeatedly so that “SURROUND OFF”
appears on the display.
1,3
2
L
LS
RS
S.WFR LFE
C
R
DIGITAL
DIGITAL AUTO
SURROUND OFF
(Back to the beginning)
Surround modes
*
2
AUTO SURROUND
*
1
HALL1
HALL2
LIVE CLUB
DANCE CLUB
PAVILION
THEATRE1
THEATRE2
MONO FILM
*
3
ALL CH STEREO
*
4
L
LS
RS
S.WFR LFE
C
R
DIGITAL
DIGITAL AUTO
SURROUND OFF
(Back to the beginning)
Surround modes
*
2
AUTO SURROUND
*
1
HALL1
HALL2
LIVE CLUB
DANCE CLUB
PAVILION
THEATRE1
THEATRE2
MONO FILM
*
3
ALL CH STEREO
*
4
1
2
3
4
5
6
7
8
9
10
0
10
1
2
