John Deere CD4039DF008 - Manual (Page 81)

Specifications
DPSG,CD03523,55 –19–10AUG99–2/3
ITEM UNIT OF MEASURE 4045HF158 4045TF158 4045TF258 4045DF158
Number of Cylinders 4 4 4 4
Fuel Diesel Diesel Diesel Diesel
Bore mm 106.5 106.5 106.5 106.5
Stroke mm 127 127 127 127
Displacement L 4.5 4.5 4.5 4.5
Compression Ratio 17.0:1 17.0:1 17.0:1 17.6:1
POWER a @ kW (hp) 88 (120) 61 (83) 72 (98) 41 (56)
1500 rpm (Prime)
POWER a @ kW (hp) 96 (131) 68 (92) 80 (109) 42 (57)
1500 rpm (Standby)
POWER a @ kW (hp) 108 (147) 72 (98) 80 (109) 48 (65)
1800 rpm (Prime)
POWER a @ kW (hp) 120 (163) 79 (107) 88 (120) 51 (69)
1800 rpm (Standby)
Width (overall) mm 798 668 668 668
Length (overall) mm 1356 1219 1219 1219
Height (overall) mm 1136 1010 1010 1010
Weight (dry) b kg 446 436 436 391
Engine oil quantity L 12 12 12 8
Engine coolant L 25 25 25 20
quantity
a With Fan
b Approximate
Continued on next page
