Jacuzzi J - LXL - Manual (Page 66)

62
LX Collection
17.7 wireless remote Battery replacement procedure
1. Turn the remote unit over and locate the battery
door (Figure A).
2. Rotate the battery door, with a coin, counterclockwise
until the dot aligns with the Open arrow (Figure B).
3. Remove battery door using coin to pry the door upward
(Figure C).
4. Replace battery using CR2025 or equivalent (Figure
D).
5. Reinstall the battery cover, using the coin to close
(Figure E).
note: Remote unit is water resistant not waterproof, therefore the unit
should be stored in a dry location within your home and never be left in
the spa while the cover is on and spa is not in use.
Battery
Door OPEN
CLOSED
Fig. A
OPEN
CLOSED
Fig. B
OPEN
CLOSED
Fig. C
LITHIUM
BATTERY
CR2025
3V
OPEN
CLOSED
Fig. D
OPEN
CLOSED
Fig. E
