LX Collection

7.0 electrical wiring Instructions

ImporTanT noTICe: The electrical wiring of this spa

must meet the requirements of the National Electrical

Code/USA (NEC) and any applicable state or local

codes. The electrical circuit must be installed by a

qualified electrician and approved by a local building/

electrical inspection authority.

1. Dedicated 240V models must be permanently connected (hard-

wired) to the power supply. No plug-in connections or extension

cords are to be used in conjunction with the operation of this spa.

Supplying power to the spa which is not in accordance with these

instructions will void both the independent testing agency listing and

the manufacturer’s warranty.

2. The power supplied to this spa must be a dedicated circuit with no

other appliances or lights sharing the power provided by the circuit.

3. To determine the current, voltage and wire size required, refer to

Section 6.0 “Power Requirements” (page 12).

Wire size must be appropriate per NEC/USA and/or local codes.

We recommend type THHN wire.

All wiring must be copper to ensure proper connections.

Do not use

aluminum wire.

4. When using wire larger than #6 (10 mm²), add a junction box near

the spa and reduce to short lengths of #8 (8.4 mm²) wire to connect

to the spa.

5. The electrical supply for this product must include a suitably rated switch

or circuit breaker to open all ungrounded supply conductors to comply

with Section 422-20 of the National Electrical Code/USA, ANSI/NFPA

70. The disconnecting means must be readily accessible to the spa’s

occupant but installed at least 5 feet (1.5m) from spa water.

6. The electrical circuit supplied for the spa must include a suitable

ground fault circuit interrupter (GFCI) as required by NEC/USA Article

680-42.

7. To gain access to the spa’s power terminal block, remove the screws

securing the synthetic cabinet corner and front panel under the

control panel (Figure A). Then remove the four control box door screws

and door (Figure B).

note: The stainless steel corners will require a square drive bit.
