9.4 J-lXl Massage/waterfall selector Diagram
massage selector operation
Rotate Massage Selector 1 to divert water between designated jet
groups.
+ _
2
2
2
1a
1b 1a
1
1b
1a
1b
3
b
1a
1a
a
massage selectors (1)
• Massage Selector #1 controls pump #1.
Jets (2)
• These jets are always on when the jets pump #2 is running.
waterfall (3)
• Waterfall is on when the jets pump 1 is running.
