DISPLAY AND SELECTIONS IN THE MENU> MODE (SETTING)

You can set the following set-up menu items.

• H. POSITION

• CONTROL LOCK

• INPUT REMOTE

• WHITE BALANCE

• STATUS DISPLAY

• ASPECT REMOTE

1. While pressing the MENU button, press the

CHROMA/PHASE button.

The screen is displayed.

2. Press the CHROMA/PHASE or CONTRAST/BRIGHT

button to select the desired menu item.

A selection mark (

3) is put next to the selected item.

3. Press the VOLUME/SELECT buttons to set.

÷ To adjust the white balance, select WHITE BALANCE and

press the VOLUME/SELECT (+) or (–) button to display the
CUT OFF or DRIVE setting screen, then adjust each setting.

÷ Press the EXIT (MENU) button to return to the

MENU> screen.

Notes:

1

Selection mark (

3): Indicates the

menu item you select.

2

Menu item: Menu items you can

select.

3

Setting display: Indicates the

current settings (value).

4

Function display: The functions of

the front panel buttons (5 buttons
on the left) correspond to the
function displayed.

Function

Contents

displayed

Forward the menu item.

5

Reverse the menu item.

Lower the adjustment
value. (to the minimum)

+

Raise the adjustment
value. (to the maximum)

3

Forward the setting value.

2

Reverse the setting value.

EXIT

Exit the
screen. (release)

DRV

Selects DRIVE adjustment.

CUTO

Selects CUT OFF
adjustment.

R·B

Adjusts red and blue
signal level.

RGB

Adjusts red, green and
blue signal level.

Turns the ON-SCREEN
display on or off. (This

DISP

function is effective only
in the DRIVE or CUT OFF
adjustment mode.)

Front panel

Function

Contents

button

displayed

CHROMA/

Forward selection mark (

3

)

PHASE

CONTRAST/

5

Reverse selection mark (

2

)

BRIGHT

Front panel

Function

Contents

button

displayed

+

Increase (to max. value)

3

Forward the setting value

CUTO

Selects CUT OFF setting screen

Decrease (to min. value)

2

Reverse the setting value

DRV

Selects DRIVE setting screen

VOLUME/

SELECT (–)

VOLUME/

SELECT (+)

÷ Parameter for H. POSITION can be set separately depending on the video input

(Input A (VIDEO) or Input B (VIDEO)) selected by the input select buttons on the front
panel.
Select the required video input with the input select buttons on the front panel in
advance.

÷ WHITE BALANCE can be set independently at 6500 or 9300 for the color temperature

value. Set COLOR TEMP. to 6500 or 9300 on the

screen beforehand.

Notes:

screen

PHASE

MENU

CHROMA

PHASE

BRIGHT

CHROMA

CONTRAST
