Specifications (contiuned) – JVC VN-V686U User Manual
Page 42
42
Ⅵ Accessories
: Start-up Guide .................................... 1
CD-ROM ............................................. 1
Ceiling Mount ...................................... 1
Dome Cover ........................................ 1
Template ............................................. 1
Wire Clamp ......................................... 1
Warranty Card (For USA).................... 1
Service Information Card (For USA) ... 1
Ⅵ Dimension [Unit: mm (inch)]
Ⅵ Ceiling mounting hole [Unit: mm (inch)]
R160(6 1/4)
2
01(7
7/
8)
199
(7 7/
8)
9
0
.5
(3 5/
8)
S
R
72
.5
(2
7
/8
)
Camera outer
diameter
FRONT mark
Front of camera
1
2
0Њ
1
2
0Њ
Screw mounting
hole
R160(6 1/4)
Mountin
g hole
R80(3
1/8)
R140(5 1/2)
Position where cables are to be
pulled out from the side
23(7/8)
22.5
(7/8)
Screw mounting hole
T Specifications and appearance of this unit
are subject to change for further
improvement without prior notice.
