References
40
7
Center unit (XV-THS1)
Audio section
Front/Center/Surrouond: 52 W per channel, RMS at 6
C at 1 kHz,
with 10 % total harmonic distortion.
Subwoofer:
52 W, RMS at 6
C at 100 Hz, with 10%
total harmonic distortion.
Digital input*:
OPTICAL DIGITAL IN:
–21 dBm to –15 dBm (660 nm
E30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz)
Video section
Video System:
PAL
Horizontal Resolution:
500 lines
Signal-to-Noise Ratio:
64 dB
(Composite signal when “RGB” is selected)
Video output level
Composite:
1.0 V(p-p)/75
C
S-video-Y:
1.0 V(p-p)/75
C
S-video-C:
0.3 V(p-p)/75
C
Tuner section
Tuning Range
FM:
87.50 MHz to 108.00 MHz
AM:
522 kHz to 1 629 kHz
General
Power Requirements:
AC 230 V
, 50 Hz
Power Consumption:
75 W (at operation)
1.0 W (in standby mode)
Dimensions (W M H M D):
360 mm M 65 mm M 370 mm
Mass:
5.3 kg
7
Front / Center speakers (SP-THS1F)
Type:
1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker:
8.0 cm cone M 1
Power Handling Capacity: 55 W
Impedance:
6
C
Frequency Range:
90 Hz to 20 000 Hz
Sound Pressure Level:
80.0 dB/W
·m
Dimensions (W M H M D):
106 mm M 119.5 mm M 102 mm
Mass:
0.49 kg each
7
Surround speakers (SP-THS1S)
Type:
1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker:
8.0 cm cone M 1
Power Handling Capacity: 55 W
Impedance:
6
C
Frequency Range:
90 Hz to 20 000 Hz
Sound Pressure Level:
80 dB/W
·m
Dimensions (W M H M D):
106 mm M 119.5 mm M 102 mm
Mass:
0.56 kg each
7
Subwoofer (SP-WS1)
Type:
1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker:
16.0 cm cone M 1
Power Handling Capacity: 55 W
Impedance:
6
C
Frequency Range:
30 Hz to 150 Hz
Sound Pressure Level:
76 dB/W
·m
Dimensions (W M H M D):
128 mm M 284 mm M 337 mm
Mass:
3.3 kg
Designs & specifications are subject to change without notice.
