TM-A101G 1-6
No.51921
ENGLISH
Functions (Items) Initialization
(setting)
SHARPNESS +03
COLOR SYSTEM AUTO
ASPECT RATIO 4–3
H. POSITION 00
WHITE BALANCE
R. CUT OFF
00
G. CUT OFF 00
B. CUT OFF 00
R. DRIVE 00
B. DRIVE 00
CONTROL LOCK OFF
STATUS DISPLAY ON
INPUT REMOTE OFF
ASPECT REMOTE OFF
PHASE 00
CHROMA 00
CONTRAST 00
BRIGHT 00
VOLUME 20
RESET
Are you sure ?
“Yes” then <+>
“No” then
Sorts
-UP
MENU> screen
Picture adjustment
V olume
HOW TO INITIALIZE THE
SETTING
SCREEN DISPLAY AND SELECTIONS IN THE
RESET MODE
You can set
1. Press the Power ( ) switch to turn the power
OFF ( G ).
The RESET screen is displayed.
* The screen automatically disappears when no operation
is performed after about 5 minutes.
Initial settings
RESET screen
2. While pressing both MENU button and CHROMA/
PHASE button, press the Power ( ) switch to turn
the power ON ( g ).
3. Setting
ⅷ Initialization is required.
ⅷ Initialization is not required.
Press the VOLUME/SELECT [+] button.
* Initialization is completed, and the
RESET screen disappears.
Press the MENU button.
* Initialization is aborted, and the
RESET screen disappears.
● The RESET screen will not be
displayed if the MENU or CHROMA/PHASE buttons are
pressed for a very short time. Keep pressing them until
the display screen appears.
Note:
11
ON
OFF
POWER
MENU CHROMA
PHASE
ON
OFF
POWER
MENU
VOLUME/SELECT
Set-up menu items Purpose Settings
H. POSITION Adjusts the horizontal position of
the screen (+ : Horizontal position
shifts to the right/–: Horizontal
position shifts to the left)
WHITE BALANCE Adjusts the white balance Selects DRIVE (DRV) or CUT OFF (CUTO) adjustment.
Screen setting is changed to the selected setting mode.
DRIVE R.DRIVE Adjusts red level
B.DRIVE Adjusts blue level
CUT OFF R. CUT OFF Adjusts red cut off
G. CUT OFF Adjusts green cut off
B. CUT OFF Adjusts blue cut off
CONTROL LOCK Sets the operation buttons on the
front panel to control lock mode
STATUS DISPLAY Sets the status display of the color
system
INPUT REMOTE Sets external control of input
selection (INPUT A/B)
ASPECT REMOTE Sets external control of the aspect
ratio
4. To set the other set-up menu items, repeat the
procedures 2 and 3.
5. Press the MENU button to quit.
Notes:
● When the CONTROL LOCK function is
set to ON, pressing operation buttons
on the front panel will display the
message “CONTROL LOCK ON!” on
the screen for about 3 seconds.
● The CONTROL LOCK function is
maintained even when the power is
turned off.
● To turn off the CONTROL LOCK
function, while holding the MENU button
press the CHROMA/PHASE button.
Then set the CONTROL LOCK function
to OFF.
● Even when the CONTROL LOCK
function is set to ON, the following
operations are available:
– Power Switch operation
– Volume control with the VOLUME/
SELECT buttons
– External control when INPUT
REMOTE or ASPECT REMOTE is
valid
– Display or disappear of the
MENU> screen.
● The STATUS DISPLAY function can be
set to display (ON) or not display (OFF)
the present color system when the
power is turned on or the input signal is
changed. Refer to page 7 for more
information.
● When the INPUT REMOTE function is
valid (ON), pressing the Input A or
Input B buttons will display the message
“REMOTE ON!” on the screen for about
3 seconds.
● To enable INPUT REMOTE or ASPECT
REMOTE, select the function on the
screen and set to
ON.
Front panel Function
Contents
button displayed
MENU EXIT
Quit (or Release) the
–05 –04 • • • • • • –01 00 +01 • • • • • • +04 +05
OFF ON
ON OFF
HOW TO USE THE MENU
FUNCTIONS
(cont’d)
10
–09 –08 • • • • • –01 00 +01 • • • • • +08 +09
–09 –08 • • • • • –01 00 +01 • • • • • +08 +09
–09 –08 • • • • • –01 00 +01 • • • • • +08 +09
–09 –08 • • • • • –01 00 +01 • • • • • +08 +09
–09 –08 • • • • • –01 00 +01 • • • • • +08 +09
OFF ON
OFF ON
