10
Basic Menu Operations
(MENU, SET-UP MENU)
7 About the Menu Screens
This monitor features MENU which contains the functions normally used and SET-UP MENU which contains the initial settings of
the monitor.
MENU
Items Functions
APERTURE Adjusts the picture aperture level.
ADJ. BAR POSI. Selects the level bar position on the screen which appears when adjusting picture or volume.
COLOR TEMP. Selects the color temperature.
COLOR SYSTEM Selects the color system.
COMPO. LEVEL 1) Adjusts the component level of the monitor for the component signal or the SDI signal.
RUSH DELAY Sets the delay time between when the stand-by button is pressed and when the monitor actually turns
on.
1) Appears only when the component signal input or the SDI signal input is selected (when INPUT C or INPUT D is selected and other signals
than RGB is input).
SET-UP MENU
Items Functions
PICTURE SUB ADJ. The standard value (“00”) of the picture adjustment is initially set at the factory. You can adjust the
standard value as your initial setting.
CONTRAST: Adjusts contrast.
BRIGHT:
Adjusts brightness.
CHROMA 2) : Adjusts color density.
PHASE 2) : Adjusts hue.
H. POSITION Adjusts the horizontal position of the screen.
V. POSITION Adjusts the vertical position of the screen.
WHITE BALANCE Adjusts the white balance.
R. CUTOFF: Adjusts the cut-off point of the red signal.
G. CUTOFF: Adjusts the cut-off point of the green signal.
B. CUTOFF: Adjusts the cut-off point of the blue signal.
R. DRIVE:
Adjusts the drive level of the red signal.
B. DRIVE: Adjusts the drive level of the blue signal.
CONTROL LOCK Prohibits the monitor operations except turning on/off the monitor and adjusting volume. The menu
operations are also prohibited.
STATUS DISPLAY Selects to display or not to display the color system of the current input on the screen.
REMOTE SYSTEM Selects the method of the external control connected to the REMOTE terminal.
INPUT REMOTE 3) Sets how to change the input when operating the monitor by the external control.
2) May not appear depending on the type of input signal.
3) Appears only when “REMOTE SYSTEM” is set to “MAKE.”
