CV-M77
11 Specifications
Scanning system Progressive 792 lines 24.8 frames/sec.
Pixel clock 25.000 MHz
Line frequency 19.685 kHz (1270 pixel clock/line)
Frame rate 24.8 frames/sec. (792 lines/frame)
CCD sensor 1/3” RGB primary color IT CCD
Sensing area 4.8 (h) x 3.6 (v) mm
Effective pixels 1034 (h) x 779 (v)
Pixels in video output 1028 (h) x 770 (v)
Cell size 4.65 (h) x 4.65 (v) µ m
Sensitivity on sensor 1.5 Lux (Max. gain, 50% video)
S/N ratio >50 dB
Video output RGB video signal, 0.7 Vpp, 75 Ω
Composite sync. on G, 0.3 Vpp (selectable)
Gamma 1.0 – 0.6 – 0.45
Gain
Gain range Manual – Automatic
-3 to +15 dB
Synchronization Int. X-tal. Ext. HD/VD or random trigger
HD sync. input/output 4 V ± 2 V, 75 Ω
Trigger input 4 V ± 2 V, 75 Ω
WEN output (write enable) 4 V ± 2 V, 75 Ω
EEN output (exposure
enable) 4 V ± 2 V, 75 Ω
Pixel clock output 4 V ± 2 V, 75 Ω
Composite sync. output 4 V ± 2 V, 75 Ω
Trigger modes Continuous, Edge pre-select,
Pulse width control (HD non-reset)
Trigger input. (Edge pre-
select) >1 H
Shutter
1/25, 1/50, 1/125, 1/250, 1/500, 1/750, 1/1000,
1/1500, 1/2000, 1/3000, 1/4000, 1/10,000 second
Programmable exposure 1.5 H to 791 H
Pulse width control 1.5 H to 2000 H
Long time exposure 2 frames to ∞
Frame-delay readout 1 H to 2000 H
Time from trigger input to ext. VD input.
For Edge pre-select and Pulse width control
Functions controlled by DIP
switch on rear Shutter speed, Trigger mode,
Readout mode, Gamma, Gain, Control
Functions controlled by
internal DIP switches VD input/output, HD input/output
HD, VD and Trigger 75 Ω termination on/off
WEN polarity, Sync. on G, White balance
Functions controlled by
RS 232C Shutter speed, Trigger mode,
Readout mode, WEN polarity, Sync on G,
Programmable exposure, Gain levels,
White clip, Setup, Gamma, White balance
Communication Baud rate 9600 bps
Operating temperature -5 ° C to +45 ° C
Humidity 20 - 80% non-condensing
Storage temp./humidity -25 ° C to +60 ° C / 20% - 80 %
Power 12V DC ± 10%, 5.5 W
Lens mount C-mount
Dimensions 40 x 50 x 90 mm (H x W x D)
Weight 270 g
Note: Above specifications are subject to change without notice.
