CV-M77
Response to firmware version request command
Example:
Request Command (PC→Camera)
Command Name
Format
Receiving Data(Camera→PC)
Remarks
Version Request
VN?
***
*** is Version No.
(3 letter)
7.4 RS232C Cable Connections
1 TXD
2 RXD
3 GND
1 CD
4 DTR
6 DSR
2 RXD
3 TXD
5 GND
7 RTS
8 CTS
9 CI
9 PIN D
COM PORT
CAMERA
6 PIN
4
5
6
