XV-THD8/XV-THD6
140 W RMS 1 kHz 4 Ω
10 %
130 W RMS 1 kHz 4 Ω
10 %
130 W RMS 1 kHz 4 Ω
10 %
140 W RMS 100 Hz 4 Ω
10 %
*
DIGITAL IN
OPTICAL – 21 dBm – 15 dBm (660 nm
± 30 nm)
COAXIAL 0.5 V(p-p)/75 Ω
VIDEO 2 AUDIO IN
PAL/NTSC
500
64 dB
1.0 V(p-p)/75 Ω
S- -Y 1.0 V(p-p)/75 Ω
S- -C PAL: 0.3 V(p-p)/75 Ω
NTSC: 0.286 V(p-p)/75 Ω
-Y 1.0 V(p-p)/75 Ω
-P B /P R 0.7 V(p-p)/75 Ω
VIDEO 2 IN
1.0 V(p-p)/75 Ω
S- -Y 1.0 V(p-p)/75 Ω
S- -C PAL: 0.3 V(p-p)/75 Ω
NTSC: 0.286 V(p-p)/75 Ω
HDMI
HDMI VIDEO 1 IN
PASS THROUGH 225 MHz
HDMI MONITOR OUT
PAL 576p/720p/1080i
NTSC 480p/720p/1080i
USB
USB USB 2.0
FAT16 FAT32
500 mA
FM 87.50 MHz 108.00 MHz
AM
10 kHz 530 kHz 1 710 kHz
9 kHz 531 kHz 1 710 kHz
AC 220 V , 50 Hz
160 W
4.0 W
Ч Ч 435 mm × 115 mm × 270 mm
6.8 kg
* PCM DTS
32 kHz 44.1 kHz 48 kHz
SP-THD8W (TH-D8)
20 cm × 1
140 W
4 Ω
28 Hz 200 Hz
75 dB/W
•
m
Ч Ч 353.5 mm × 351 mm × 248 mm
8.5 kg
SP-THD6W (TH-D6)
20 cm × 1
140 W
4 Ω
28 Hz 200 Hz
75 dB/W
•
m
Ч Ч 353.5 mm × 351 mm × 248 mm
8.5 kg
