59
% Center unit (XV-THM45)
Audio section
Total Harmonic Distortion 0.02 %
NOTE: This value is measured at System cord CONNECTOR for
reference.
Audio input sensitivity/Impedance (at 1 kHz)
Analog input:
AUDIO IN (VCR):
290 mV/47 k
C
MIC:
4.3 mV/600
C
Digital input*:
DIGITAL IN (DBS):
–21 dBm to –15 dBm
(OPTICAL)
(660 nm
E30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz)
Video section
Color System:
NTSC/PAL selectable
Horizontal Resolution:
500 lines
Signal-to-Noise Ratio:
64 dB
Video output level
Composite:
1.0 V(p-p)/75
C
S-video-Y:
1.0 V(p-p)/75
C
S-video-C:
0.286 V(p-p)/75
C
Component-Y:
1.0 V(p-p)/75
C
Component-P
B
/P
R
:
0.7 V(p-p)/75
C
Video input sensitivity/Impedance (VCR IN)
Composite:
1.0 V(p-p)/75
C
S-video-Y:
1.0 V(p-p)/75
C
S-video-C:
0.286 V(p-p)/75
C
Tuner section
Tuning Range
FM:
87.50 MHz to 108.00 MHz
AM:
531 kHz to 1 602 kHz
(at 9 kHz intervals)
530 kHz to 1 600 kHz
(at 10 kHz intervals)
General
Power Requirements:
AC 240 V
Ó, 50 Hz
Power Consumption:
20 W (at operation)
1.6 W (in standby mode)
Dimensions (W
M H M D):400 mm M 85 mm M 386 mm
Mass:
4.6 kg
% Subwoofer (SP-PWM45)
Amplifier section
Front/Center/Surround:
80 W per channel, RMS at 6
C at
1 kHz, with 10 % total harmonic
distortion.
Subwoofer:
120 W, RMS at 4
C at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit:
16 cm Bass-reflex, Magnetically
Shielded
Frequency Range:
30 Hz to 200 Hz
General
Power Requirements:
AC 240 V
Ó, 50 Hz
Power Consumption:
140 W (at operation)
0 W (in standby mode)
Dimensions (W
M H M D):216 mm M 353 mm M 485 mm
Mass:
12.0 kg
% Satellite Speakers
Front speakers (SP-THM45F)
Speakers:
8.0 cm
Bass-reflex, Magnetically Shielded
Power Handling Capacity: 80 W
Impedance:
6
C
Frequency Range:
90 Hz to 20 kHz
Dimensions (W
M H M D):103 mm M 115 mm M 100 mm
Mass:
0.64 kg
Surround speakers (SP-THM45S)
Speakers:
8.0 cm
Bass-reflex, Magnetically Shielded
Power Handling Capacity: 80 W
Impedance:
6
C
Frequency Range:
90 Hz to 20 kHz
Dimensions (W
M H M D):103 mm M 115 mm M 100 mm
Mass:
0.52 kg
% Center Speaker (SP-THM45C)
Speakers:
8.0 cm
Bass-reflex, Magnetically Shielded
Power Handling Capacity: 80 W
Impedance:
6
C
Frequency Range:
90 Hz to 20 kHz
Dimensions (W
M H M D):103 mm M 115 mm M 100 mm
Mass:
0.64 kg
Specifications
