17
Operation of the external control
1
Set “TYPE SEL.” of “REMOTE SETTING” to “MAKE” or “TRIGGER” in the SET-UP MENU.
2
Short-circuit the 7th pin terminal (ENABLE) to the 8th pin terminal (GND) so that the monitor can be controlled
by the external control.
3
When the “MAKE” system is selected: Operate each function by short-circuiting the corresponding pin terminal
to the 8th pin terminal (GND) or opening it.
When the “TRIGGER” system is selected: Operate each function by pulse control, that is short-circuiting the
corresponding pin terminal to the 8th pin terminal (GND) for about 1 second and opening it.
• When changing the input with MAKE system, only one pin terminal must be short-circuited. (Other pin terminals
must be opened.)
• When selecting the TRIGGER system, you can operate only one function at a time. Operate the functions one
by one.
7 Using the RS-232C system
You can control the monitor from a personal computer etc. via the RS-232C terminal.
• Consult your dealer for the details of the external control specification.
Data Bits: 8 bits
Parity: No parity
Stop Bits: 1 bit
Flow Control: No control
Communication Code: ASCII Code
• Use a straight cable with a D-sub 9-pin connector (male for the monitor, female for the personal computer).
Header
Monitor ID (00)
Command ID
Function
Data
Cr (0Dh)
Header
“!”: Operation commands from the personal computer, etc. For details, see
“?”: Reference commands from the personal computer, etc.
“@”: Status returns from the monitor
• To start communication, send the connection command from the personal computer etc.
• To terminate the communication, send the termination command from the personal computer etc.
Example of communication procedures
1 Starting the communication: connection command
(!00BCN1Cr)
3 Selecting “SDI 1” input (!00BINACr)
5 Terminating the communication: termination command
(!00BCN0Cr)
6 Monitor’s status (@00BOKCr)
4 Monitor’s status (@00BOKCr)
2 Monitor’s status (@00BOKCr)
PC, etc.
Monitor
This is a female
terminal.
Pin No.
Signal
1
NC
2
RXD
3
TXD
4
NC
5
GND
6
NC
7
RTS
8
CTS
9
NC
• The 7th terminal and the 8th terminal are connected.
No.
Commands
Functions
Data
1
!
0
0
B C N 1
Cr
Starts communication (connection)
No data
2
!
0
0
B C N 0
Cr
Terminates communication (termination)
No data
3
!
0
0
B M E N U Cr
Displays the MAIN MENU/Quits the menu
operation
No data
4
!
0
0
B U P Cr
Moves the cursor upward ( )
No data
5
!
0
0
B D O W N Cr
Moves the cursor downward ( )
No data
6
!
0
0
B A D J
R Cr
Makes setting/adjustment ( )
No data
7
!
0
0
B A D J
L
Cr
Makes setting/adjustment ( )
No data
8
!
0
0
B S E T U P
Cr
Displays the SET-UP MENU
No data
9
!
0
0
B P W 1
Cr
Turns on the monitor
No data
10
!
0
0
B P W 0
Cr
Turns off the monitor (standby)
No data
11
!
0
0
B I
N A Cr
Selects “SDI 1” input
No data
12
!
0
0
B I
N B Cr
Selects “SDI 2” input
No data
13
!
0
0
B I
N C Cr
Selects “VIDEO/COMPO.” input
No data
14
!
0
0
B D I
S P Cr
Displays the status*
2
No data
15
!
0
0
B V P L
S Cr
Increases the volume level
No data
16
!
0
0
B V M N S Cr
Decrease the volume level
No data
17
!
0
0
B V O L
x
x*
1
Cr
Adjusts the volume level
00 – 30
18
!
0
0
B A M U T E
x
x*
1
Cr
Turns muting on/off
00: Off, 01: On
19
!
0
0
B A S P x
x*
1
Cr
Changes the aspect ratio
00: 4:3, 01: 16:9
• “Cr” is 0Dh.
• The commands for starting communication (connection) (No. 1), terminating communication (termination)
(No. 2), and turning on the monitor (No. 9) can be used while the monitor is off (on standby).
*
1
Enter the appropriate data to “xx”.
*
2
Displays the information shown when the button of the current input is pressed (
☞ “On the Status Display” on page 7).
