2
Thank you for purchasing this product.
(These instrustions are for TK-WD310U and TK-WD310E.)
Before beginning to operate this unit, please read the instruction
manual carefully in order to make sure that the best possible per-
formance is obtained.
Features
Ⅵ Backlight compensation over a wide area is realized by the 14-bit
Wide Dynamic Range feature.
The Wide Dynamic Range feature controls the exposure time using
a maximum of 5 sampling timing for the image within a single screen.
Even when shooting in areas with large difference in lightning, sub-
jects with difference in brightness can be viewed in a clear and natu-
ral state.
Ⅵ 1/3-inch high-resolution DPS device adopted as shooting element
to realize high picture quality with no smearing or blooming in areas
with high luminance. In addition, 1.9lx (during F1.2, 50%, AGC HIGH
setting) is realized for minimum subject brightness.
Ⅵ Horizontal resolution of 480 lines (typ.) and vertical resolution of over
400 lines allow display of finely detailed video.
Ⅵ New device adopted for use even under strong electric field condi-
tions.
Ⅵ Compatible with CS mount and VIDEO auto iris/DC auto iris.
* When using the C mount lens, C mount adapter is required.
Ⅵ Various settings in each menu screen are possible.
Menu settings can be performed easily using single button opera-
tions.
Ⅵ 3 white balance modes of ATW, AWB and MANUAL are available.
ATW mode that adjusts the white balance automatically according
to the changes in lighting conditions (color temperature) or AWB/
MANUAL mode that automatically or manually adjusts and locks the
white balance of specific lighting conditions can be selected.
Ⅵ Camera title setting and display can be made.
Ⅵ Compact design allows installation in narrow spaces.
INTRODUCTION
