Names and Operations of Parts
[Side Panel]
COLOR VIDEO CAMERA
IRIS
DC
VIDEO
D [VIDEO/DC] Iris Selector Switch
This should be set according to the type of lens if an automatic iris
control lens is used.
VIDEO : In case of lens with EE amp built-in.
(
੬ Page 20)
DC
: In case of lens without EE amp built-in.
(
੬ Page 14)
(DC : At time of factory shipment)
E [IRIS] Iris Terminal
This is connected to an automatic iris control lens.
(
੬ Page 15)
INTRODUCTION
