14
ENGLISH
Menu item
Selectable setting, [Initial: Underlined]
COLOR SETUP
*
2
DAY
COLOR *
3
BUTTON ZONE You can create your own day and night colors for
and
Perform step
2 to select a primary color (RED/ GREEN/ BLUE),
then adjust the level [
00 — 31]. Repeat this procedure until you
have adjusted all the three primary colors.
• If “
00” is selected for all the primary colors for
nothing appear on the display.
DISP ZONE
NIGHT
COLOR *
4
BUTTON ZONE
DISP ZONE
MENU COLOR ON : Changes the display and buttons (except for
DISP / BRIGHTNESS /
0)
illumination during menu, list search and playback mode operations. /
OFF : Cancels.
DIMMER
DIMMER SET
AUTO : Dims the display to the previous setting when you turn on the car headlights.*
5
/
ON : Dims the display and button illumination. / OFF : Cancels.
BRIGHTNESS
DAY [ 31 ] / NIGHT [ 15 ] : Selects the display and button illumination brightness
level [
00 — 31] for day and night.
DISPLAY
SCROLL *
6
ONCE : Scrolls the displayed information once. / AUTO : Repeats scrolling (at 5-second
intervals). /
OFF : Cancels.
(Pressing
DISP for more than one second can scroll the display regardless of the setting.)
TAG DISPLAY ON : Shows the Tag information while playing MP3/WMA tracks. / OFF : Cancels.
PRO EQ
For settings, see page 13.
AUDIO
FADER *
7,
*
8
R06 — F06 [ 00 ] : Adjusts the front and rear speaker output balance.
BALANCE *
8
L06 — R06 [ 00 ] : Adjusts the left and right speaker output balance.
LOUD
ON : Boost low and high frequencies to produce a well-balanced sound at a low volume
level. /
OFF : Cancels.
VOL ADJUST
–05 — +05 [ 00 ] : Presets the volume adjustment level of each source (except
“FM”), compared to the FM volume level. The volume level will automatically increase or
decrease when you change the source. Before adjustment, select the source you want to
adjust. (“VOL ADJ FIX” appears on the display if “FM” is selected as the source.)
L/O MODE *
9
SUB.W : Selects if the REAR/SW terminals are used for connecting a subwoofer (through
an external amplifier). /
REAR : Selects if the REAR/SW terminals are used for connecting
the speakers (through an external amplifier).
SUB.W
(For KD-A525) ON : Turns on the subwoofer output. / OFF : Cancels.
*
2
For KD-R528.
*
3
Displayed only when
*
4
Displayed only when
*
5
The illumination control lead connection is required. (See “Installation/Connection Manual.”) This setting may not work
correctly on some vehicles (particularly on those having a control dial for dimming). In this case, change the setting to
any other than
*
6
Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*
7
If you are using a two-speaker system, set the fader level to “00.”
*
8
This adjustment will not affect the subwoofer output.
*
9
For KD-R528/KD-R520/KD-R428/KD-R420.
