1 – EN

KD-S27

CD RECEIVER : INSTRUCTIONS/INSTALLATION

0710DTSMDTJEIN

EN
© 2010 Victor Company of Japan, Limited

GET0698-001A

[J]

1

Turn on the power.


2

3

Canceling the display demonstration

4

Select <

DEMO OFF

>.

5

6

Finish the procedure.

Setting the clock

1

Turn on the power.


2

3

Select <

CLOCK

>.


4

Select <

CLOCK SET

>.

5

Adjust the hour.


6

Adjust the minute.


7

Finish the procedure.

Preparations

For safety...

• Do not raise the volume level too much, as this will

block outside sounds, making driving dangerous.

• Stop the car before performing any complicated

operations.

Temperature inside the car...

If you have parked the car for a long time in hot or
cold weather, wait until the temperature in the car
becomes normal before operating the unit.

Basic operations

When you press or hold the following button(s)...

Main unit

Remote

controller

General operations

Turns on.
• When the power is on, pressing /I/ATT on the remote controller

also attenuates the sound or pauses. Press /I/ATT again to cancel
muting or resume playback.

Turns off if pressed and held.

Selects the available sources (if the power is turned on).
• If the source is ready, playback also starts.

Adjusts the volume level.

Selects items.

• Mutes the sound while listening to a source. If the source is “CD” or

“USB,” playback pauses. Press the control dial again to cancel muting
or resume playback.

• Confirms selection.

Selects the sound mode.
• Enters tone level adjustment directly (see page 3) if pressed and held

EQ BASS-TRE

on the main unit.

Enters playback mode menu directly (see page 2).

Power off : Checks the current clock time.
Power on : Changes the display information.

[European Union only]

Warning:

If you need to operate the unit while driving, be sure
to look around carefully or you may be involved in a
traffic accident.

(Initial setting)

[Hold]

(Initial setting)

[Hold]

Control dial

Loading slot

Display window

Auxiliary input jack

Ejects the disc

Detaches the panel

USB (Universal Serial
Bus) input jack

INFORMATION (For U.S.A.)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.

Caution:

Changes or modifications not approved by JVC could void the user’s authority to operate the equipment.

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all

servicing to qualified service personnel.

3. CAUTION: (For U.S.A.)

Visible and/or invisible class II laser radiation when open. Do not stare into beam.

(For Canada) Visible and/or invisible class 1M laser radiation when open. Do not view directly

with optical instruments.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.

Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to
ensure your complete understanding and to obtain the best
possible performance from the unit.

For customer Use:
Enter below the Model No. and Serial No. which are located
on the top or bottom of the cabinet. Retain this information
for future reference.
Model No.
Serial No.

Remote sensor

• DO NOT expose to bright sunlight.

Returns to the previous menu

How to attach/detach the control
panel

How to reset your unit

Reset the unit after installation is
completed.
• Your preset adjustments will

also be erased.

How to forcibly eject a disc

• You can forcibly eject the loaded disc even if the

disc is locked. To lock/unlock the disc, see page 2.

• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.

Preparing the remote controller
(RM-RK50)

When you use the remote controller for the first time,
pull out the insulation sheet.

If the effectiveness of the remote controller
decreases, replace the battery.

Replacing the lithium coin battery

For USA-California Only:
This product contains a CR Coin Cell Lithium Battery
which contains Perchlorate Material—special
handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate

Caution:

• Danger of explosion if battery is incorrectly

replaced. Replace only with the same or equivalent
type.

• Battery shall not be exposed to excessive heat such

as sunshine, fire, or the like.

Warning (about battery handling)

To prevent accidents and damage:
• Do not install any battery other than CR2025 or its

equivalent.

• Store out of reach of children.
• Do not recharge, short, or dismantle.
• Do not dispose of in fire.
• Do not carry around with other metallic materials.
• Wrap the battery with tape and insulate when

throwing away or saving it.

[Hold]

Insulation sheet

CR2025
