References
34
7
Center unit (XV-THS11B)
Audio section
Front/Center/Surround:
33 W per channel, RMS at 6
C at 1 kHz,
with 10% total harmonic distortion.
Subwoofer:
40 W, RMS at 4
C at 100 Hz, with 10%
total harmonic distortion.
Video section
Video System:
NTSC
Horizontal Resolution:
500 lines
Signal-to-Noise Ratio:
64 dB
Video output level
Composite:
1.0 V(p-p)/75
C
S-video-Y:
1.0 V(p-p)/75
C
S-video-C:
0.286 V(p-p)/75
C
Component (Interlace/Progressive):
Y: 1.0
V(p-p)/75
C
P
B
/P
R
: 0.7
V(p-p)/75
C
Tuner section
Tuning Range
FM:
87.5 MHz to 108.0 MHz
AM:
530 kHz to 1 710 kHz
Speaker impedance
Front/Center/Surround:
6
C to 16 C
Subwoofer:
4
C to 16 C
General
Power Requirements:
AC 120 V
, 60 Hz
Power Consumption:
135 W (at operation)
1.3 W (in standby mode)
Dimensions (W M H M D):
360 mm M 65 mm M 370 mm
Mass:
5.3 kg
7
Front speakers (SP-THS11BF)
Type:
1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker:
8.0 cm cone M 1
Power Handling Capacity: 33 W
Impedance:
6
C
Frequency Range:
90 Hz to 20 000 Hz
Sound Pressure Level:
84 dB/W·m
Dimensions (W M H M D):
92 mm M 101 mm M 95 mm
Mass:
0.58 kg each
7
Center speaker (SP-THS11BC)
Type:
1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker:
8.0 cm cone M 1
Power Handling Capacity: 33 W
Impedance:
6
C
Frequency Range:
90 Hz to 20 000 Hz
Sound Pressure Level:
85 dB/W·m
Dimensions (W M H M D):
92 mm M 101 mm M 95 mm
Mass:
0.65 kg
7
Surround speakers (SP-THS11BS)
Type:
1-Way Bass-Reflex Type
Speaker:
8.0 cm cone M 1
Power Handling Capacity: 33 W
Impedance:
6
C
Frequency Range:
90 Hz to 20 000 Hz
Sound Pressure Level:
82 dB/W·m
Dimensions (W M H M D):
92 mm M 101 mm M 95 mm
Mass:
0.56 kg each
7
Subwoofer (SP-THS11BW)
Type:
1-Way Bass-Reflex Type
Speaker:
15.0 cm cone M 1
Power Handling Capacity: 40 W
Impedance:
4
C
Frequency Range:
40 Hz to 1 800 Hz
Sound Pressure Level:
84 dB/W·m
Dimensions (W M H M D):
129 mm M 284 mm M 337 mm
Mass:
3.0 kg
Designs & specifications are subject to change without notice.
