26
The following functions can be performed via iView
2
:
Function
Description
Unit Configuration
Display/modify unit information.
Port Configuration
Display/modify port data.
Tables Display
statistics
tables,
including Unit and Port tables, RMON
statistics, MIB-II ifTable and SFP Info.
VLAN Provides
configuration for VLAN IDs per port
Advanced
Reboot the module; also allows boot trap delay.
OAM AH
Configure passive and active 802.3ah
OAM CFM
Perform administrative configuration functions.
Agent Info
Displays SNMP agent data.
Refresh
Allows the unit to be refreshed after changes are made
Unit Configuration
Select Unit Configuration to
display/modify unit information including IP address (display
only, modification not allowed), global flow control, maximum frame size and OAMPDU:
NOTE
Entering a descriptor in the Description field can make it easier to track down the source of a
TRAP.
