Normally, you can complete the setup procedure using Automatic Image S etup;
however, if your screen image is still distorted after you perform Image S etup or
the setup CD does not run on your system, perform M ANUAL I MAGE S ETUP .
To manually adjust the image setting, do the following:
1. Have your monitor turned on for about 15 minutes, until the monitor
warms up.
2. Display the image you most frequently use on the screen.
3. Press the OSD Enter button at the bottom of the monitor to display
the initial OSD menu.
4. Use the Right Arrow button( ) to select the IMAGE SETUP icon
and press the OSD Enter button to access the function.
5. Use the Right Arrow button( ), to select to MANUAL. Press the OK
button ( )twice to select COLOK.
6. Use the Arrow buttons to manually adjust to correct (as much as
possible) for jitter or noise in the image. Press OK button( ).
7. Press OK( ) and use Arrow buttons to adjust PHASE, press OK( ).
Press OK( ) again to Save and Exit. Then press Cancel button( )
twice to exit OSD.
You have completed the monitor setup.
ENGLISH
15
i If the monitor is in standby
mode (STANDBY ON), it
might automatically turn off
while you are waiting for it to
warm up.
Manual Image Setup
